Cybotix – 12kw Hybrid Inverter with WIFI

Cybotix 12kW Solar Inverter with Dual MPPT

The Cybotix 12kW solar inverter is the heavy-duty choice for large homes, commercial buildings, and businesses with high energy demand. It features dual MPPT solar inputs and supports a 48V battery system (40-60V DC), so it delivers powerful, reliable solar energy and strong backup when the grid goes down.

Dual MPPT Inputs for Flexible Solar Design

This dual MPPT solar inverter has two independent MPPT trackers, each with a 90-500V input range. You can connect two separate panel strings facing different directions, such as east and west roofs, or arrays with different shading. Each string runs at its own optimal power point, so you harvest more energy across the whole day.

12kW Output for Demanding Loads

With 12kW of continuous output, this 12000W inverter can power multiple air conditioners, refrigerators, water pumps, washing machines, lighting, and office equipment at the same time. It suits large households and businesses that need to run heavy appliances on solar power. Always keep the combined load, including motor startup surges, within the inverter’s capacity.

48V Battery System for Reliable Backup

The inverter operates with a 48V battery bank in a 40-60V DC range. The higher battery voltage keeps current low, which improves efficiency, reduces heat, and supports large lithium or lead-acid banks for extended backup during outages.

Robust Build for Large Installations

Measuring 540 × 350 × 120 mm and weighing 19.5 kg, the Cybotix 12kW inverter is built for serious installations while still wall-mounting neatly in plant rooms, garages, and utility areas.

Ideal For

• Large homes running multiple air conditioners
• Commercial buildings, offices, and clinics
• Factories, workshops, and retail stores
• Backup power during load shedding and grid failures
• Large off-grid homes and farmhouses

Technical Specifications

Frequently Asked Questions

What is the benefit of dual MPPT in a solar inverter?
Dual MPPT lets you connect two separate solar strings, each optimised on its own. This is ideal when panels face different directions or one section gets shade, because a weaker string doesn’t pull down the output of the other.

How many air conditioners can a 12kW inverter run?
A 12kW inverter can run several air conditioners along with other household loads. The exact number depends on each unit’s power rating and startup surge, so add up all connected loads and keep the total within 12000W.

How should I connect solar panels to this inverter?
Connect your panels in two series strings, one per MPPT input, keeping each string’s voltage within the 90-500V range. Panel voltage rises in cold weather, so leave a safety margin below 500V. A qualified installer can design the best layout.

What is the difference between the Cybotix 6.2kW and 12kW inverters?
The 12kW model delivers nearly double the output power and adds a second MPPT input for more flexible solar design. Both use a 48V battery system, but the 12kW is built for larger homes and commercial sites with heavier loads.
